Description

1.input Way : Floating and defibrillation protection

2.Lead : Standard 12 leads

3.atient leak current : <10μA

4.Input Impedance: >50ΜΩ

5.Frequency response : 0.05Hz ~ 150Hz (-3dB)

6.Time constant : Time constant > 3.2s

7.CMRR : > 60dB, > 100dB (Adding Filter)

8.EMG interference filter : 35 Hz (-3dB)

9.Recording way : Thermal printing system

10.Specification of recording paper : 210mm (W) x 20m (L) high-speed thermal paper

11.Paper speed : Auto record : 25mm/s, 50mm/s, error : ± 5%

12.Rhythm record : 25mm/s, 50mm/s, error : ± 5%

13.Manual record : 5mm/s, 6.25mm/s, 10mm/s, 12.5mm/s, 50mm/s, error : ± 5%

14.Sensitivity selections : 5, 10, 20, 40mm/mV, error : ± 5%. Standard sensitivity is 10mm/mV ± 2mm/mV.

15.Auto record : Record setup according to auto record format and mode, automatically changing leads, measuring and analyzing.

16.Rhythm record : Record setup according to rhythm record format and mode, automatically measuring and analyzing.

17.Manual record : Record setup according to manual record format, manually changing leads.

18.Measurement parameters : HR, P-R. interval, P Duration, QRS Duration, T Duration, Q-T interval,

19.Q-Tc, P Axis, QRS Axis, T Axis, R(VS), S(VI), R(VS) + S(VI)

20.Product safety type : Class I CF applied part; there is defibrillation and packing protection circuit in it.

21.Enduring polarization voltage : ± 500mV

22.Noise level : <15μVp-p

23.Size : 334mm (L) x 320mm (W) x 85m (H)

24.Power supply / Frequency : AC : 100 – 240V, 50/60Hz DC:14.8V, 3700mAh rechargeable lithium battery
