Description

1. Innovative Design
• Color Matching Fume Hoods break the monotone of traditional market
products.
• Stylish design with functional durability

2. Cabinet Structure
• Made of acid-resistant, alkali-resistant, and corrosion-resistant PP
material.
• Reinforced with “mouth”, “U”, and “T” type structures for stable physical
strength.
• Super bearing capacity, durable for long-term use

3. Working Table
• Standard: same PP material as cabinet body.
• Customizable with other materials according to customer requirements

4. Glass Window
• Made of 5 mm tempered glass.
• High strength, excellent bending resistance.
• Breaks safely without producing sharp fragments.

5. Window Sliding Door
• Integrated molding design (customizable).Movable vertical sliding door
separates workspace from operator for safety.
• Can stop at any position with balance support
• Provides a clear, unobstructed field of vision

6. Window Frame and Suspension
• Frameless door, embedded on all four glass sides.
• Low friction resistance, ensuring safety and durability.
• Adjustable timing belt (5 mm × 11.5 sheath, steel wire reinforced) for
door suspension

7. Deflector System
• Made of 8.0 mm brand-new PP plate, welded and corrosionresistant.
Installed behind and above the workspace.
• At least three plates forming an air chamber between workspace and
exhaust pipe.
• Ensures even discharge of polluted gases.
• Detachable and reassemble-friendly with deflector clips

8. Air Collection Hood
• Made of PP color matching plate.
• Air outlet diameter: 250 mm.
• Rectangular bottom inlet + circular top outlet.
• Strong resistance to corrosion, efficient airflow

9. Lighting
• Equipped with 1 × 30W LED fluorescent lamp.
• Waterproof, anti-corrosion, anti-oxidation design for safe lab use

10. Control Panel
• LCD control panel for clear status display.
• Includes power, switch, lighting, fan, and indicator buttons.
• User-friendly and intuitive control

11. Lower Cabinet
• Made of welded PP color plate, carved and bent in one piece.
• Double-folded door panels – sturdy, resistant to deformation, and
attractive design

12. Hardware and Accessories
• Laboratory-specific PP hinges – strong corrosion resistance.
• Waterproof sockets – four provided with each fume hood

13. Sink and Water Trap
• Sink: PP cup trough, strong corrosion resistance.
• Filtering and odor-blocking functionality.
• Water trap elbow: made of high-density PP for durability
